Godox KNOWLED AM1600R RGB Inflatable LED Light Mat (230 x 230cm)

Name: Godox KNOWLED AM1600R RGB Inflatable LED Light Mat (230 x 230cm)
Brand: Godox
SKU: G/AM1600R8*8
Price: 175000.00 ZAR
Availability: InStock

R 175,000.00

The Godox KNOWLED AM1600R 8 × 8 is a 230 × 230 cm full-colour LED mat built for large film, television, broadcast and virtual-production sets. Its inflatable butterfly frame creates a broad, lightweight soft source without a conventional truss structure and can reach 8 psi in approximately three minutes.

The AM1600R covers 1800K to 10,000K with CCT, HSI, RGBW, GEL and FX modes, plus full green/magenta correction. CRI 96 and TLCI 97 support accurate colour, while 0–100% dimming, four dimming curves and 14 effects provide detailed creative control.

Professional control options include onboard operation, wired DMX/RDM, LumenRadio CRMX, Ethernet protocols and Bluetooth app control from up to 60 m. Both the light body and controller carry an IP54 rating for dust and splash resistance during demanding studio and location work.

The supplied soft film, two diffuser fabrics, pancake lantern, grid and skirt can be used individually or combined to change softness and spill. The complete system packs into the included flight case, and the supplied repair kit supports efficient field maintenance of the inflatable frame.

Godox Godox KNOWLED AM1600R RGB Inflatable LED Light Mat (230 x 230cm)

R 175,000.00

Technical Specifications

Product Specifications

Brand: Godox KNOWLED
Model: AM1600R, 8 × 8 version
Broadcast Bros SKU: G/AM1600R8*8
Fixture type: Full-colour flexible LED mat with inflatable butterfly frame
Light body dimensions: Approximately 230 × 230 cm
CCT range: 1800K to 10,000K
Colour modes: CCT, HSI, RGBW, GEL and FX
Green/magenta adjustment: -100% to +100%
Dimming: 0–100% with linear, S-curve, exponential and logarithmic curves
Lighting effects: 14
Colour accuracy: CRI ≈96; TLCI ≈97
Control: Onboard, DMX/RDM, CRMX, Ethernet, Bluetooth app and NFC pairing
Bluetooth range: Up to 60 m
Protection rating: IP54 for light body and controller
AC input: 100–240 V, 50/60 Hz, 1800 W
Controller dimensions: Approximately 27 × 22 × 37 cm
Controller weight: Approximately 11 kg
Operating temperature: -20°C to 45°C

Product FAQ

Which AM1600R size is this listing for?
This is the 8 × 8 version with an approximately 230 × 230 cm light body.

How long does the inflatable frame take to set up?
Godox states that it reaches 8 psi in approximately three minutes and can remain inflated for up to 15 days under suitable conditions.

Can it connect to professional lighting-control systems?
Yes. It supports wired DMX/RDM, LumenRadio CRMX, Ethernet protocols, onboard control and Bluetooth app control.

Is it suitable for location use?
Yes. The light body and controller are IP54 rated for dust and splash resistance, but normal electrical and weather precautions still apply.

Which light-shaping accessories are included?
The kit includes soft film, two diffuser fabrics, a pancake lantern, grid and skirt, plus the inflatable frame, pump, controller and flight case.

Who Is This For?

Cinematographers and gaffers lighting large film, television and virtual-production sets.

Broadcast studios and rental houses that need a large full-colour source with professional networked control.

Location crews requiring a portable overhead or wraparound soft source with IP54 protection.

What's Included

What's Included

Godox KNOWLED AM1600R 8 × 8 light body
Inflatable butterfly frame
Controller
Controller mounting bracket
Air pump
Two diffuser fabrics
Pancake lantern
Fabric grid
Spill-control skirt
Soft film
Repair kit
Optical accessories kit
AC power cord
DC power cord
Flight case
Two-year local warranty
